PRVirconJoyAdd()
Adds a new virtual joystick to the PRVircon UI.
Declaration
PRVirconJoyAdd(name, nubSprite, outlineSprite, hAlign, vAlign, xOffsetPos, yOffsetPos, scale, rotation)
Parameters
name
The name to assign to the new joystick. Useful for tracking it in the GMS debugger and can be used to lookup the joystick's ID.
nubSprite
The sprite image to use for the joystick's nub.
outlineSprite
The sprite image to use for the joystick's bounds outline.
hAlign
Set to PRVirconHAlignLeft, PRVirconHAlignCenter or PRVirconHAlignRight. Determines if the joystick's X offset should be relative to the left, center or right side of the GUI display.
vAlign
Set to PRVirconVAlignTop, PRVirconVAlignMiddle or PRVirconVAlignBottom. Determines if the joystick's Y offset should be relative to the top, middle or bottom of the GUI display.
xOffsetPos
The x position of the joystick, relative to either the left, center or right of the GUI display, depending on the value given in hAlign.
yOffsetPos
The y position of the joystick, relative to either the top, middle or bottom of the GUI display, depending on the value given in vAlign.
scale
How much to scale the joystick sprites, with 1 being no scaling. Larger values will increase the size of the sprites while values lower than 1 will decrease the size of the sprites.
rotation
The angle at which to rotate the joystick sprites in degrees.
Return Value
The new virtual joystick's ID.
